Industrial Pallet Cage
The industrial pallet cage is used in workshops where parts, cartons, and metal components need temporary storage and internal transport. Its foldable structure reduces floor space requirements after unloading, while the stackable frame keeps material flow organized between production and storage areas.
Model No.: HM-HD001
Exterior Dim.: 1030L×840W×850H mm
Wire Gauge: 6 mm
Grid Size: 50×50 mm
Loading Capacity: 1300 kg
Loaded in 1x40'HQ: 500 sets
Products Description
Industrial Pallet Cage
Manufacturing Excellence
Expertise Supplier
Warehouse Solutions
Reliability Partner
Benefits
Stacked: 4 open
Zinc/hot dip galvanized/powder coating
Collapsible to save space
Accessories: Wheels/inner PP sheet or PP hollow sheet/bag
Available design: Top lid/bar runner/forklift guide/with inner divider
HM-HD001
Model No.
1300 kg
Loading Capacity
1030x840x850 mm
Exterior dimension
500sets
Loaded in 1X40'HQ
This industrial pallet cage is manufactured from mild steel Q235 with a welded wire mesh structure for repeated industrial handling. Standard size is 1030 × 840 × 850 mm with 6 mm wire diameter and 50 × 50 mm mesh spacing. Standard loading capacity is 1300 kg, suitable for heavy components, packaged hardware, and workshop materials. Forklift entry allows direct movement between storage locations, production zones, and shipping preparation areas. The frame folds flat when empty for more compact storage and return handling.
Advantages
- Reduces floor space usage after unloading
- Prevents loose parts from shifting during movement
- Allows forklift transfer across workshop zones
- Front gate improves access during picking tasks
- Supports vertical storage for more efficient warehouse layout
Products Customized
This industrial pallet cage can be customized with a reinforced forklift channel based on workshop equipment and handling frequency. Some industrial facilities request thicker fork contact areas to manage repeated loading cycles or heavier material transfer. Modified fork pocket dimensions can also match existing pallet systems already used inside the plant. This option is common for stackable pallet cage projects involving continuous internal transport.
Application
The industrial pallet cage is commonly placed in industrial workshops where materials move between machining, assembly, inspection, and packing stations. Operators use it for die parts, metal fittings, fasteners, and boxed accessories requiring temporary staging. The wire mesh structure is also useful near production lines where goods wait for the next handling step. During internal logistics, forklift drivers can relocate full units without additional repacking.
Hot Tags: industrial pallet cage, China, suppliers, manufacturers, factory, customized, buy, price, for sale, in stock, free sample, made in China
Specification
|
Model No. |
Exterior dimension |
Wire Gauge |
Dimension of Grid |
Loading capacity |
Loaded in 1x40'HQ |
|
LxWxH(mm) |
mm |
mm |
kg |
sets |
|
|
HM-HD001 |
1030x840x850 |
6 |
50x50 |
1300 |
500 |
|
HM-HD005 |
1230x1040x900 |
6.2 |
50x100 |
1000 |
350 |
|
HM-HD010 |
1200x1000x1250 |
6 |
25x50 |
800 |
216 |
|
HM-HD028 |
1200x1000x1140 |
5 |
50x100 |
500 |
270 |
|
Material |
Mild steel Q235 |
||||
|
Other design |
Top lid/bar runner/forklift guide/with inner divider |
||||
|
Available accessories |
Wheels/ iron sheets/ PP hollow sheets |
||||
|
Remark |
Customized or OEM support |
||||
Similar Specification
This industrial pallet cage is also available in related configurations with different dimensions, mesh spacing, door styles, and height options for alternative storage layouts. Customers managing different material types often combine standard workshop cages with taller, lighter-duty, or galvanized versions within the same warehouse system. Related models maintain the same folding structure and forklift handling features while adapting to specific operational needs.
Video
HM Group manufactures steel storage equipment for warehouse storage, material handling, and transport operations. Our product range includes industrial pallet cages, stackable racks, and customized steel storage systems for repeated warehouse use. Watch the video to view our production process and contact us for project specifications, bulk orders, or OEM requirements.
HM Group
——
Hold Goods, Move World
- Experienced manufacturer and exporter since 2003.
- Export Quantity: Around max 300 containers per month in 2023
- 10 production bases in 7 cities: Dalian, Qingdao, Xiamen, Nanjing, Hangzhou
- Offer custom-designed to suit your every need
- OEM, ODM support
Production Process
This industrial pallet cage is produced through scheduled welding lines supported by stable raw material stock and batch production planning. Monthly output reaches 12000 sets, with weekly capacity around 3000 sets for regular export orders. Standard models stay within active production schedules, which helps maintain shorter lead times. Packaging uses plastic banding and stretch film, suitable for forklift or pallet jack movement during container loading.
Quality Control
Before shipment, this industrial pallet cage completes a loading capacity verification test. The unit is loaded to rated working weight, then stacked for structural inspection. This process checks weld integrity, base alignment, and frame deformation after vertical loading. This confirms the unit meets standard warehouse stacking requirements.
Packing and shipping
1. Plastic banding with steel pallet
2. Stretch film wrapping
Certificate
We are dedicated to showing that we are a dependable and exceptional partner for all of your requirements.
What Customers Say
"We use this unit in our fabrication workshop to move metal components between storage and assembly. The folding structure saves space after unloading, and the shipment arrived well packed ready for direct warehouse unloading."------Sandra Andrade
FAQ
Q: Can this industrial pallet cage be used in workshops with heavy materials?
A: Yes. The loading capacity is 1300 kg, suitable for industrial components and packed materials.
Q: Does the cage fold without tools?
A: Yes. Side panels collapse manually for flat storage when empty.
Q: Can the unit be moved by forklift from multiple sides?
A: Yes. Forklift entry is designed for routine warehouse and workshop movement.
