Warehouse Storage Pallet Cage
The warehouse storage pallet cage is suitable for facilities where bulk goods require organized temporary storage without adding fixed racking systems. Its foldable structure reduces empty storage space, while the stackable frame makes better use of vertical storage during daily inventory handling.
Model No.: HM-HD001
Exterior Dim.: 1030L×840W×850H mm
Wire Gauge: 6 mm
Grid Size: 50×50 mm
Loading Capacity: 1300 kg
Loaded in 1x40'HQ: 500 sets
Products Description
Warehouse Storage Pallet Cage
Benefits
Stacked: 4 open
Zinc/hot dip galvanized/powder coating
Collapsible to save space
Accessories: Wheels/inner PP sheet or PP hollow sheet/bag
Available design: Top lid/bar runner/forklift guide/with inner divider
HM-HD001
Model No.
1300 kg
Loading Capacity
1030x840x850 mm
Exterior dimension
500sets
Loaded in 1X40'HQ
This warehouse storage pallet cage for repeated warehouse use. Standard size is 1030 × 840 × 850 mm, built with 6 mm wire diameter and 50 × 50 mm grid spacing. The open mesh design allows quick visual inventory checks, and the foldable side panels reduce occupied space after unloading. Forklift access is integrated into the base for routine warehouse handling and transport. The steel frame also supports stable vertical stacking during daily storage operations.
Advantages
- Supports vertical storage through loaded stacking
- Folds flat to reduce empty storage space
- Improves inventory visibility during stock inspection
- Keeps packaged goods contained during storage and movement
- Moves easily by forklift between warehouse zones
Products Customized
This warehouse storage pallet cage can be produced with customized surface treatment based on storage environment requirements. Powder coating is commonly selected for indoor warehouse projects, while zinc galvanized or galvanized finishes are often used where moisture contact or longer storage cycles are involved. Surface finish adjustments are frequently requested when stored goods require cleaner product contact conditions or when warehouse equipment needs a more uniform appearance.
Application
The warehouse storage pallet cage is often used for store pulp products, paper-based materials, and compressed packaged goods inside warehouse facilities. Operators can place loaded units in bulk storage zones, dispatch staging areas, or temporary overflow sections during inventory peaks. The folding structure is practical when seasonal stock levels fluctuate.
Hot Tags: warehouse storage pallet cage, China, suppliers, manufacturers, factory, customized, buy, price, for sale, in stock, free sample, made in China
Specification
|
Model No. |
Exterior dimension |
Wire Gauge |
Dimension of Grid |
Loading capacity |
Loaded in 1x40'HQ |
|
LxWxH(mm) |
mm |
mm |
kg |
sets |
|
|
HM-HD001 |
1030x840x850 |
6 |
50x50 |
1300 |
500 |
|
HM-HD005 |
1230x1040x900 |
6.2 |
50x100 |
1000 |
350 |
|
HM-HD010 |
1200x1000x1250 |
6 |
25x50 |
800 |
216 |
|
HM-HD028 |
1200x1000x1140 |
5 |
50x100 |
500 |
270 |
|
Material |
Mild steel Q235 |
||||
|
Other design |
Top lid/bar runner/forklift guide/with inner divider |
||||
|
Available accessories |
Wheels/ iron sheets/ PP hollow sheets |
||||
|
Remark |
Customized or OEM support |
||||
Similar Specification
Additional models are available with different heights, door layouts, and wire configurations for alternative storage requirements. Related models are commonly used in facilities managing lighter packaged products, taller inventory formats, or different access requirements. The same foldable structure is used across different warehouse storage applications.
Video
See how the warehouse storage pallet cage is manufactured for warehouse storage and material handling operations. HM Group produces stackable steel storage equipment for organized inventory, forklift handling, and daily logistics use. Watch the video to view our production process or contact us for project specifications and bulk orders.
HM Group
——
Hold Goods, Move World
- Experienced manufacturer and exporter since 2003.
- Export Quantity: Around max 300 containers per month in 2023
- 10 production bases in 7 cities: Dalian, Qingdao, Xiamen, Nanjing, Hangzhou
- Offer custom-designed to suit your every need
- OEM, ODM support
Production Process
This warehouse storage pallet cage is produced through planned welding lines supported by stable steel inventory and standard batch manufacturing. Monthly capacity reaches 12000 sets, with weekly output around 3000 sets for export projects and repeat warehouse orders. Regular production scheduling helps maintain stable lead times for standard specifications. Packaging uses plastic banding and stretch film for direct forklift or pallet jack handling.
Quality Control
Before shipment, this warehouse storage pallet cage completes a dimensional inspection. Production staff checks frame size, mesh spacing, and folding alignment against standard drawings before packing. This inspection confirms structural consistency and verifies whether folding sections and stacking points meet standard dimensional tolerances before shipment.
Packing and shipping
1. Plastic banding with steel pallet
2. Stretch film wrapping
Certificate
We are dedicated to showing that we are a dependable and exceptional partner for all of your requirements.
What Customers Say
"We use these units for warehouse storage of packaged pulp materials and paper products. Stacking improved our storage layout noticeably, and folded cages were easier to store after stock turnover."--------Adriana Lourenço
FAQ
Q: Can this industrial pallet cage be used in workshops with heavy materials?
A: Yes. The loading capacity is 1300 kg, suitable for industrial components and packed materials.
Q: Does the cage fold without tools?
A: Yes. Side panels collapse manually for flat storage when empty.
Q: Can the unit be moved by forklift from multiple sides?
A: Yes. Forklift entry is designed for routine warehouse and workshop movement.
