Warehouse Stacking Racking
This warehouse stacking racking with mesh base supports smaller tires, stacks 4 high when in use, and saves 80% space when disassembled.
Model No.:HM-TR7272WM
Exterior Dimension:72"×72"×72"
Loading Capacity:2400 lb. / 1100 kg
Max. Stacked:4 open
Max. Stacked:20 closed
Tire Capacity:42 to 63 pcs
Application area: Warehouse, logistics, tyre, auto industry
Products Description
Warehouse Stacking Racking
Manufacturing Excellence
Expertise Supplier
Warehouse Solutions
Reliability Partner
Benefits
Max. Stacked:4 open
Max. Stacked:20 closed
Tire Capacity:42 to 63 pcs
Powder coating (customized)
Fully detachable to save space
HM-TR7272WM
Model No.
2400 lb. / 1100 kg
Loading Capacity
72"×72"×72"
Exterior dimension
130 sets
Loaded in 1x40'HQ
This warehouse stacking racking uses the standard 72"×72"×72" size and adds a wire mesh to the base. The metal mesh helps support the smaller tires and keeps them off the warehouse floor for more efficient storage. The removable column design saves up to 80% of space when not in use and can tightly stack up to 20 tires at a time. Each rack has a load capacity 1,100 kg and can be stacked 4 layers when fully loaded.
Advantages
1. Ease of Loading/Unloading: Simplifies handling for employees.
2. Enhanced Aesthetics: A tidy storage space improves facility appearance.
3. Mobility: Portable designs offer flexible storage solutions.
4. Regulatory Compliance: Meets safety and health storage guidelines.
5. Increased Productivity: Quick access boosts workflow and productivity.
Products Customized
Application
This warehouse stacking racking works well for transport hubs or logistics centers. Warehouses use them to organize tires for delivery trucks, buses, or other fleet vehicles. Each rack loading capacity 1100 kg and stacks four high. Tires are easy to find and pick up thanks to the open sides. When not needed, tyre stacking racks can be disassembled to save space. This solution is helpful for seasonal tire storage too, especially when dealing with summer or winter tire types. It keeps the warehouse neat and improves workflow.
Hot Tags: warehouse stacking racking, China, suppliers, manufacturers, factory, customized, buy, price, for sale, in stock, free sample, made in China
Specification
|
Model No. |
HM-TR7272WM |
|
Exterior Dim. LxWxH |
72"x72"x72" |
|
Load capacity |
2400LB./1100 kg |
|
Materials |
Steel |
|
Max.Stacked(open) |
4 |
|
Max. Stacked(closed) |
20 |
|
Tire capacity |
42 to 63 |
|
Loading 1*40'HQ |
130 sets |
|
Features |
Mobile, stackable, foldable/removable sides |
|
Tire type |
Passenger tire & light tire |
|
Color |
Orange |
|
Finish |
Powder coated |
|
Warranty |
1 year |
Similar Recommended
|
Model No. |
Exterior Dimension LxWxH |
Tire capacity pcs |
Loading Capacity |
Max. Stacked open |
Max. Stacked closed |
1*40'HQ sets |
|
HM-TR6060 |
60"x60"x60" |
24 to 32 |
2400LB./1100 kg |
4 |
20 |
280 |
|
HM-TR-LR |
85"X 48 1/2" X 50" |
34 to 50 PCR-SUV - 7 TBR |
2400 lb. / 1100 kg |
6 |
20 |
140 |
|
HM-TR-FD |
72''x50''x80'' |
28 to 50 |
2400lb./1100 kg |
4 |
20 |
101 |
|
HM-TR1 |
2290x1100x1250mm |
36 to 55 |
600 kg |
4 |
20 |
110 |
|
HM-TR10 |
96"x46"x51" |
35 to 65 |
2400 lb. / 1100 kg |
4 |
20 |
70 |
|
HM-FR002 |
1521x1000x1360mm |
- |
500 kg |
4 |
20 |
126 |
|
Remark |
Customized or OEM support |
|||||
Add additional base wire mesh to the floors. Want to speed up return logistics? We can adjustable the warehouse stacking racking to nest flat when disassembled. Add nameplates for lot tracking, or hook points for securing straps during transport.
Video
Ready to boost garage organization? Watch assembly guide for warehouse stacking racking! We break down each step and important details to ensure assembly is smoothly. Don't miss it!
HM Group
——
Hold Goods, Move World
- Experienced manufacturer and exporter since 2003.
- Export Quantity: Around max 300 containers per month in 2023
- 10 production bases in 7 cities: Dalian, Qingdao, Xiamen, Nanjing, Hangzhou
- Offer custom-designed to suit your every need
- OEM, ODM support
Production Process
Our factory boasts a production capacity of 6,000 tons, ensuring we meet the demands of clients consistently. We utilize advanced technology to streamline our processes, allowing us to produce high-quality products efficiently and reliably.
Quality Control
Surface Treatment Checks – Protecting Against Corrosion.
For steel products, surface treatment is critical to durability. Whether it's powder coating or galvanization, HM Group team verifies the thickness and quality of the surface coating. This protects against corrosion, making sure the steel storage racks and other products last for years, even in damp or outdoor conditions.
Packing and shipping
1. Easy to load & unload with the forklift.
- 4 up support tube
- Fix & Protect
2. Plastic film
- Fix & Protect, against moisture & rust
3. Steel straps
- Avoid breaking
Certificate
Our commitment compliance with certifications including ISO, SGS inspection, BV test, APT test, and a patent certificate, ensuring the high standards for HM Group
What Customers Say
We used to struggle with damaged tires from poor storage. Since switching to HM’s racks with bottom mesh, we’ve had zero product loss. They keep everything off the ground and well-supported. Simple but effective design.
FAQ
Q: Are your tire racks easy to assemble or fold down?
A: Yes, all racks are designed to be assembled or folded in minutes, without special tools. This helps save labor and makes transport easier.
Q: What’s the loading capacity of standard tire racks?
A: Each rack can loading capacity 1100 kg when fully loaded. They’re strong enough for heavy truck and equipment tires.
Q: How high can the racks be stacked?
A: Most models stack 4 layers high when set up. Folded racks can stack up to 20 high for space-saving storage.
Q: Do you offer different sizes for different tire types?
A: Yes, we have standard 60"x60" and 72"x72" racks, and we can also customize sizes for specific tire models or spaces.
