Warehouse Portable Tire Rack
Designed for light truck tire storage, the warehouse portable tire rack is built for fast-moving operations that need both flexibility and strength. Its detachable and stackable design helps warehouses save space while keeping tire handling simple and efficient.
Model No.:HM-TR-LR
Exterior Dimension:85" x 48.5" x 50"
Load capacity: 2400 lb / 1100 kg
Max. Stacked:6 open
Max. Stacked:20 closed
Tire Capacity:34 to 50 light truck tires
Products Description
Warehouse Portable Tire Rack
Manufacturing Excellence
Expertise Supplier
Warehouse Solutions
Reliability Partner
Benefits
Max. Stacked:6 open
Max. Stacked:20 closed
Tire Capacity:34 to 50pcs
Powder coating (customized)
Tire type: Light truck tire
Fully foldable to save space
HM-TR-LR
Model No.
2400 lb. / 1100 kg
Loading Capacity
85''x48.5''x50''
Exterior dimension
140sets
Loaded in 1* 40'HQ
This warehouse portable tire rack is made from mild steel Q235; it has a load capacity of 2,400 lbs per rack and stacks up to six levels when fully loaded. Both sides are detachable for easy storage, helping you store up to 20 empty racks compactly near loading docks.
Advantages
1. Space-saving design: Max. Stacked 20 closed - It helps make better use of warehouse space. This is especially useful when storage area is limited.
2. Easy to stack: Max. Stacked 6 open - Multiple racks can be stacked neatly on top of each other. This improves storage efficiency and keeps the area organized.
3. Strong Mild steel Q235: The structure is built for industrial environments. It offers solid support and better durability.
4. Built for heavy loads - It can handle the weight(2400lbs) of stored tires with stability. This makes it suitable for busy storage environments.
Products Customized
We offer custom sizes, colors, and surface treatments to match your warehouse demands. Options include powder coating, galvanized finish, and different heights or widths. Bottom mesh options can also be added based on your storage needs.
Application
Ideal for busy tire distribution centers, this warehouse portable tire rack improves unloading speed and reduces handling time. Workers can quickly move warehouse metal tire rack with forklifts and stack them safely. It works especially well in logistics staging areas where frequent loading and unloading are required.
Hot Tags: warehouse portable tire rack, China, suppliers, manufacturers, factory, customized, buy, price, for sale, in stock, free sample, made in China, tire storage shelf, best tire storage rack, tire rack tire storage, tire rack for garage wall, tire rack spare tire, rack wheel
Specification
|
Model No. |
HM-TR-LR |
|
Exterior Dim. LxWxH |
85''x48.5''x50'' |
|
Load capacity |
2400LB./1100 kg |
|
Materials |
Steel |
|
Max. Stacked(open) |
6 |
|
Max. Stacked(closed) |
20 |
|
Tire capacity |
34 to 50 |
|
Loading 1*40'HQ |
140 sets |
|
Features |
Mobile, stackable, foldable/removable sides |
|
Color |
Blue/ orange |
|
Finish |
Powder coated |
|
Warranty |
1 year |
Similar Recommended
|
Model No. |
Exterior Dimension LxWxH |
Tire capacity pcs |
Loading Capacity |
Max. Stacked open |
Max. Stacked closed |
1*40'HQ sets |
|
HM-TR6060 |
60"x60"x60" |
24 to 32 |
2400LB./1100 kg |
4 |
20 |
280 |
|
HM-TR6 |
90"x 40"x 52" |
34 to 50 |
2400 lb. / 1100 kg |
6 |
20 |
90 |
|
HM-TR-FD |
72''x50''x80'' |
28 to 50 |
2400lb./1100 kg |
4 |
20 |
101 |
|
HM-TR1 |
2290x1100x1250mm |
36 to 55 |
600 kg |
4 |
20 |
110 |
|
HM-TR10 |
96"x46"x51" |
35 to 65 |
2400 lb. / 1100 kg |
4 |
20 |
70 |
|
HM-FR002 |
1521x1000x1360mm |
- |
500 kg |
4 |
20 |
126 |
|
Remark |
Customized or OEM support |
|||||
You may also consider stackable tire rack with posts for easier access, open on four sides, such as the HM-TR7272WM, suitable for light-duty tires. For tire storage, we have a variety of warehouse portable tire rack for you to choose from.
Video
See how this warehouse portable tire rack improves daily warehouse operations. With its stackable and foldable design, it allows faster unloading and organized storage in one simple system. Whether you're handling passenger tires or truck tires, this helps reduce handling time and keeps your workspace clear and efficient.
HM Group
——
Hold Goods, Move World
- Experienced manufacturer and exporter since 2003.
- Export Quantity: Around max 300 containers per month in 2023
- 10 production bases in 7 cities: Dalian, Qingdao, Xiamen, Nanjing, Hangzhou
- Offer custom-designed to suit your every need
- OEM, ODM support
Production Process
Production starts with steel cutting and forming. Structures are welded by robot arms or skilled workers to ensure that the connection is more secure. After welding, the warehouse portable tire rack goes through sandblasting for surface cleaning, followed by powder coating or galvanizing for corrosion resistance. Production capacity available for bulk orders is sufficient to meet your order needs.
Quality Control
The warehouse portable tire rack undergoes load capacity testing to ensure it can safely hold 2,400 lbs(1,100kg). We also perform stacking stability tests to verify safety when they are stacked up to six levels. If this is your first time using this steel tire rack, we can provide videos on using forklifts for stacking as a guide for safe stacking.
Packing and shipping
Pack in strict accordance with the packaging requirements to ensure that the product will not be damaged during transportation.
Certificate
Our commitment to compliance with certifications, including ISO, SGS inspection, BV test, APT test, and a patent certificate, ensures the high standards for HM Group
What Customers Say
“We needed it for our distribution center, and this warehouse portable tire rack worked. It’s strong, easy to move, and saves a lot of space when folded. The supplier also responded quickly and helped us customize sizes.” --Brett Lazar
FAQ
Q: What types of tires can this warehouse portable tire rack store?
A: This is designed for light truck tires.
Q: What is the load capacity of each industrial tire rack?
A: Each can safely load up to 2,400 lbs when fully loaded, ensuring reliable performance for heavy-duty warehouse use.
Q: How many tires can one portable tire rack hold?
A: One rack can store up to 50 tires, depending on size and stacking method.
Q: Can they be stacked when loaded?
A: Yes, they can be stacked up to 6 levels high when fully loaded, helping maximize vertical warehouse space.
