Warehouse Fabric Storage Rack

During production peaks, finished fabric rolls can quickly exceed the available space in fixed storage areas. Warehouse fabric storage rack units provide a flexible way to create temporary vertical storage rows on open floor areas without installing permanent shelving. By moving rolls away from forklift routes and production passages, these racks help maintain a cleaner storage layout while keeping materials accessible when needed.

Model No.:HM-FR002
Exterior Dimension: 1521x1000x1360 mm
Load capacity: 500 kg
Stackability: 2 - 4tiers
Load in 1x40HQ: 126pcs
Color: Powder coating color as per request

Send Inquiry

Download

Products Description

Fabric Warehouse Racks

Warehouse Fabric Storage Rack

Manufacturing Excellence

Expertise Supplier

Reliability Partner

Benefits

Foldable to save space

Warehouse, logistics, and the textile industry

HM-FR002

Model No.

500 kg

Loading Capacity

1521×1000×1360 mm

Exterior Dimension

126 sets

Loaded in 1X40'HQ

Warehouse fabric storage racks are designed for textile facilities that need flexible storage during changing production volumes. The side structure can be folded down when the racks are empty, reducing the space required for return storage. When the side structure are locked into position, the Q235 steel structure transfers the weight of stacked units through the structure instead of directly onto the fabric rolls below. The forklift entry design allows operators to move complete batches instead of handling individual rolls repeatedly.

The folding structure also allows warehouse teams to adjust storage layouts according to daily production requirements. When demand increases, the racks provide vertical storage capacity. When inventory decreases, empty units can be folded and stored with less impact on floor space.

Advantages

✔ Maximizes warehouse capacity without increasing floor occupancy
✔ Empty units can be dismantled and stored in a smaller area
✔ Reinforced steel frame maintains rack stability under full loading conditions
✔ Designed for efficient transport between storage, inspection, and production zones
✔ Clear product visibility simplifies stock identification and material retrieval

Details carpet roll storage rack

Products Customized

Different textile facilities have different roll sizes, handling equipment, and warehouse layouts. The warehouse fabric storage rack can be customized according to roll diameter, roll length, forklift height, and available aisle space. For larger rolls, the side structure height can be adjusted to provide sufficient clearance between stacked layers. The base dimensions and steel tube thickness can also be modified according to required loading capacity.

fabric rolls storage racks Customization Options

Application

Warehouse personnel sort finished fabric rolls by production batch before loading them onto the stillages for fabric rolls. Instead of being transferred directly into production, the loaded racks are positioned throughout the warehouse according to inventory planning and stock availability. Each rack serves as a dedicated storage unit until specific rolls are requested for downstream manufacturing or customer orders. Once the stored materials have been removed, the upright posts are detached, and the rack bases are nested together to minimize the occupied storage footprint before the next loading operation.

Fabric Racks for Rolled Fabric Applications

Hot Tags: warehouse fabric storage rack, China, suppliers, manufacturers, factory, customized, buy, price, for sale, in stock, free sample, made in China

Specification

Model No.	Exterior Dimension	Loading Capacity	Loaded in 1x40'HQ
Model No.	LxWxH	kg	pcs
HM-FR001	1520x1380x1251 mm	1500	82
HM-FR002	1521x1000x1360 mm	500	126
HM-FR003	1540x1200x984 mm	1000	90
HM-FR004	1100x1100x900 mm	1000	80
HM-FR005	1500x1100x900 mm	1100	320
HM-FR006	1500x1100x1600 mm	1100	288
HM-FR007	48x48x36 inch	1100	380

Similar Specification

Different textile materials require different storage structures. Reinforced stacking racks are commonly used for heavier yarn packages that require higher load support. Nesting racks are suitable for facilities where empty units need to be cleared frequently from staging areas.

carpet-beating-rack-Similar-Models

Video

This video shows how a warehouse fabric storage rack is folded after use, helping reduce occupied space when racks are not loaded. Built for fabric roll storage and warehouse handling, the steel structure supports stacking, transport, and daily material movement in textile facilities. Contact us for customized sizes, product details, or bulk order requirements.

HM Group

——

Hold Goods, Move World

- Experienced manufacturer and exporter since 2003.

- Export Quantity: Around max 300 containers per month in 2023

- 10 production bases in 7 cities: Dalian, Qingdao, Xiamen, Nanjing, Hangzhou

- Offer custom-designed to suit your every need

- OEM, ODM support

Production Process

The main frame and folding joints of the warehouse fabric storage rack are welded using automated welding equipment to ensure consistent joint strength. After welding, the steel surface undergoes sandblasting prior to coating to enhance surface quality and coating adhesion.

carpet roll dispenser rack Manufacturing Factory

Quality Control

Batches of warehouse fabric storage rack is checked for structural dimensions, folding operation, and stacking alignment. The folding mechanism is tested to ensure the side structure open and lock correctly during repeated warehouse handling.

rolling fabric rack Quality Inspection

Packing and shipping

- Each unit is protected with plastic strapping and stretch film to facilitate safe transport and efficient loading or unloading using forklifts or pallet jacks.

- We also provide customized packaging solutions based on customer requirements.

fabric roll display rack Packaging
